Model: VC317
Mfr. No.: 3416
Colour, sizing or style depicted in some photos may not be exactly as described.
Please check your product description carefully before placing your order.
Nominal Height:
Log in to access pricing, other warehouse availability and place orders.
Nominal Height
16'
Material
Aluminum
Capacity
300 lbs.
Base Width
37"
Base Depth
102"
ANSI Type
1A
CSA Grade
1A
Highest Standing Point
160"
Open Height
182"
Weight
70 lbs.
STEPLADDER
| Max. Height You Want to Reach* | Buy This Size |
|---|---|
| 7' | 4' |
| 8' | 5' |
| 9' | 6' |
| 10' | 7' |
| 11' | 8' |
| 12' | 10' |
| 14' | 12' |
| 16' | 14' |
| 18' | 16' |
| 20' | 19' |
| 22', 24' | 20' |
*Assumes a 5' 6" person with a vertical 12" reach.
LOAD CAPACITY CHART
| 200 lbs. | CSA Grade 3 Household |
| 225 lbs. | CSA Grade 2 Tradesman and Farm |
| 250 lbs. | CSA Grade 1 Construction and Industrial |
| 300 lbs. | CSA Grade 1A (ANSI Type1A) Construction and Industrial Heavy Duty |
| 375 lbs. | CSA Grade 1AA (ANSI Type1AA) Construction and Industrial Extra Heavy-Duty |
Keep your body centered on the ladder.
Hold the ladder with one hand while working with the other hand whenever possible. Never let your belt buckle pass beyond either ladder rail
Move materials with extreme caution.
Be careful pushing or pulling anything while on a ladder. You may lose your balance or tip the ladder
DON'T stand above the highest safe standing level
DON'T stand above the second step from the top of a stepladder and the 4th rung from the top of an extension ladder. A person standing higher may lose their balance and fall.
Fully open the stepladder and firmly lock both spreaders
Position the ladder so you can face your work and do not have to lean sideways
Be sure that all ladder feet are on firm, level ground.
Don't place a ladder on slippery surfaces or place loose materials underneath a ladder. Solid footing is necessary for safe ladder use
